UPC/EAN/JAN Supplemental AIM ID Format (Parameter #672, SSI #F1h A0h)
If Transmit Code ID Character (Parameter #45, SSI #2Dh) is set to AIM Code ID Character, this parameter selects an output format when reporting UPC/EAN/JAN bar codes with supplementals.
- Separate—transmits UPC/EAN/JAN with supplementals with separate AIM IDs but one transmission.Example
]E<0 or 4><data>]E<1 or 2>[supplemental data]
- Combined—transmits UPC/EAN/JAN with supplementals with one AIM ID and one transmission, i.e.:Example
]E3<data+supplemental data>
- Separate Transmissions—transmits UPC/EAN/JAN with supplementals with separate AIM IDs and separate transmissions, i.e.:Example
]E<0 or 4><data>
]E<1 or 2>[supplemental data]
Scan one of the following bar codes to select an output format. By default, this parameter is set to Combined.
